GOIP-16 Channels GSM Gateway Exporter China

GOIP-16 Channels GSM Gateway

Our GoIPs come with all the common network, VoIP, and GSM features and they have been widely tested for compatibility, stability, and reliability. In addition, we’ve developed our proprietary Remote SIM technology for SIM card management without inserting SIM cards to GoIPs. Together with the SMS Server and SIM Sever, you can now build your own system for voice traffics between VoIP and GSM or a SMS Messaging system based on your application requirements. In addition, each GoIP is equipped with a Remote Control client which enables a secure remote access method for technical support and GoIP management. All of the above features are available at no additional charges.

Call from VoIP to GSM or GSM to VoIP
Bulk SMS
Auto check balance and recharge
Remote SIM Control
Outbound call from voip
Inbound call from gsm
Remote management

GSM Channels: 16 ports
Power Adapter: DC 12V/4A
CPU: ARM11/700MHz
RAM: 128M
Flash: 8M
GSM Frequency: 850/900/1800/1900MHz
Max power consumption: 30W
Net weight: 0.90KG
Size:29*14.5*5.5cm
Operating Tempreture: 0-45℃
Working Humidity: 10%-90% non condensation
VoIP Protocols: SIP V2, H.323 V4
Audio Codecs: g711(alaw/ulaw), g729, g723.1
DTMF format: SIP INFO, RFC2833, Inband
Packet Loss Concealment
Programmable Jitter Buffer: Fixed, Dynamic, Adaptive
Network Connection: DHCP, PPPOE, Static IP
STUN Server
Support English, Chinese
Support Signaling encryption
Support media encryption
Support Media NAT Traversal
Support Remote control

The concept diagram below shows a simple VoIP network for call center application. It consists of a softswitch/IP PBX and VoIP clients such as an IP phone, a call center operator, and GoIPs. All VoIP clients are configured to register to the softswitch/IP PBX. For the GoIPs, each GSM channel is inserted with a valid SIM card in order to access the GSM network. Both incoming and outgoing calls between the VoIP and GSM/PSTN networks can now be realized.
